OQAN QLS 8AB

The OQAN QLS 8AB is a portable powered speaker designed to offer versatility and practicality in various usage scenarios, such as small events, presentations, musical activities, or outdoor use. It integrates a rechargeable lithium-ion battery with a runtime of up to approximately 4 hours, allowing for use even in the absence of direct power supply.

The system is equipped with an 8” woofer and a 1” driver, delivering a peak power of up to 190W, ensuring a clear and balanced sound for both voice and music. The 3-channel mixer allows for direct connection of microphones, instruments, or line sources via 2 combo XLR inputs, in addition to an AUX input (RCA and 3.5 mm mini jack) for external devices. There is also a Line XLR output for connecting to additional speakers.

The integrated DSP manages sound processing with features such as equalization, reverb, limiter, and feedback control. Four preset modes (Music, Speech, Monitor, and Sub) are available to quickly adapt the sound output to the specific context of use.

The wireless audio port with TWS (Twin Wireless System) technology enables wireless stereo reception and the connection of two units wirelessly. Weighing 7 kg and featuring compact dimensions (27 x 27.5 x 40 cm), the QLS-8AB represents a practical and easily transportable solution for vocal and musical amplification.

• Mic/Line/Instrument: 2 combo XLR inputs
• AUX Input: 1 RCA + 1 mini jack (3.5 mm)
• Equalization: Treble, Bass, ±15 dB
• Line Output: 1 XLR
• DSP: sampling frequency 48 kHz, feedback detector, crossover, limiter, talkover, reverb, parametric EQ
• DSP Modes: 1. Music 2. Speech 3. Monitor 4. Sub
• Wireless audio port with TWS (Twin Wireless System)
• Peak Power: 190W (LF 130W + HF 60W)
• Total Harmonic Distortion (THD): <0.1% (20Hz–20kHz)
• Rechargeable lithium battery: 11.1V, 6.6Ah
• Approximate Battery Life: 4 hours
• Speakers: LF 8″ + HF 1″
• Dimensions: 27 x 27.5 x 40 cm
• Weight: 7 kg
